Wire tightener compact version for roll up - PU = 200 pcs
Application area: Tensioning device for wire ropes in roll screen systems, especially for tight installation spaces Material: High-quality steel, Sendzimir galvanized for optimal corrosion protection Installation: Secured exclusively with M6 screws for safe and stable fixation Special feature: Compact design allows space-saving installation Advantages: Enhanced wire tension stability Durable construction thanks to galvanized steel Ideal for roll screen systems in greenhouses Prevents unwanted slack in the wire The Compact wire tensioner for roll screen is specifically designed for tight installation spaces in shading systems. Its compact design enables stable wire tension and ensures reliable fastening. Made from Sendzimir galvanized steel, the component offers optimal corrosion protection. Installation is carried out exclusively with M6 screws, ensuring particularly secure fixation. This makes the tensioner ideal for use in greenhouses where precise and long-lasting wire tension is required. The construction prevents unwanted slack and maintains consistent tension over extended periods. Users also benefit from increased overall wire guidance stability, making the tensioner an indispensable element in professional roll screen systems.
Bolts M 6 x 30 with nuts for steel tube 27.32 - PU = 50 pcs
Application: Connecting push-pull tubes Ø 27 and Ø 32 mm in greenhouse systems Dimensions: M6 × 30 mm Material: Galvanized steel Features: Bolt head and nut sit flush with the tube to avoid collision with roller housings Packaging unit: 50 pieces The Bolts M6×30 with nuts for steel tube 27.32 are designed for connecting 27 mm and 32 mm push-pull tubes in greenhouse shading and ventilation systems. The flush fit prevents interference with diabolo roller housings.
Poly cord, Black line -
Application: Vertical wind protection cord for outdoor roll-up screens Diameter: 8 mm Length: 300 m per spool Material: Polyester, highly UV-resistant The Poly cord, Black line – Ø 8 mm – spool = 300 m is vertically tensioned as a wind protection element for outdoor roll-up screens. It is made of UV-stabilized polyester for long-term outdoor use.
Al. tube for roll up curtains 50mm Type 2 L=6,40mm - 2 grooves
Das ideale Rollschirmrohr für Twin-Rollschirme. Es ist ausgestattet mit zwei Nuten zum Einführen des Gewebes.Material: Aluminium
Steel tube galv. narrowed, 1'' / 2,5mm / L= 6,50 m
This steel tube is used as a drive shaft for ventilation systems and large shading systems in greenhouses.Due to its wall-thickness of 2,50 mm, it is resistant against torsion.The tubes can be easily connected by inserting them into each other through their swaged ends and bolting them afterwards. Bolt M8 x 50 with a nyloc nut M8 are neededDiameter: 1 Wall thickness: 2.5 mmLength: 6500 mmMaterial: Galvanised Steel
Steel tube, galvanized swaged
This steel tube is particular stable. It is used as a push-pull-tube for shading- and ventilation systems in greenhouses. The tubes can be easily connected by inserting them into each other through their swaged ends and bolting them afterwards. Bolt and nut 27.32 for steel tubes are needed.Diameter: 27 mm Wall thickness: 1.5 mm Length: 6500 mm Material: Galvanized Steel
Adapter for telescope on
Application: Adapter between telescopic drive unit and 50 mm roll-up tube Material: Aluminum Compatibility: Fits with TGU telescopic unit (e.g. item 24100407) Use case: For lightweight greenhouses and side ventilation systems The Adapter for telescopic unit to Ø 50 mm roll-up tube enables connection between a telescopic drive (e.g. TransAxleUnit) and a 50 mm roll-up tube. Ideal for lightweight greenhouse structures such as foil tunnels. Made of durable aluminum and easy to install.
Telescopic Shaft 1220 - 1695 mm
Application: For automatic or manual drive systems to open and close side ventilation Length: Adjustable from 1220 mm to 1695 mm Material: Aluminium housing with stainless steel piston rod Mounting: Quick installation via proven double-flat coupling Compatibility: Suitable for fixed-mounted motors Max. drive angle: 34° The Telescopic Shaft 1220–1695 mm is a compact and maintenance-free TransAxleUnit for lightweight greenhouse structures such as poly tunnels. Its telescopic design allows flexible adjustment and easy integration into side ventilation systems.
Motor gearbox Ridder RW 45-3\400-450 Volt
Application: Drive unit for ventilation and screen systems in greenhouses or barns Voltage: 400–450 V, 3~, 50 Hz Speed: 3 rpm Limit switch: Integrated linear limit switch system with a 97-turn operating range Features: Self-locking worm gear for secure shaft position at standstill Quiet operation due to optimized gear combinations Maintenance-free and compact design Optional RPU PositioningUnit or potentiometer feedback Graphite-grey powder coating Ridder Article No.: 502010 The RW 45-3 / 400–450 V is a compact and maintenance-free gear motor for greenhouse ventilation and shading systems. It features a self-locking worm gear, a precise linear limit switch system, and optional feedback integration for climate control systems.
Motor gearbox RW 405 - 400-450 Volt - 3 Phase / 5,0 rpm - Ridder Art.-Nr.: 502220
Application: Drive unit for ventilation, shading, and lifting systems in greenhouses or livestock buildings Voltage: 400–450 V, 3-phase Speed: 5 rpm Protection class: IP55 – sealed housing with linear limit switch system End switch: Patented linear system with operating and safety switches (adjustable up to 86 turns) Features: Self-locking worm gear, quiet operation, graphite-grey powder coating Optional: RPU PositioningUnit or potentiometer feedback kit Ridder Article No.: 502220 The RW405 motor gearbox is a compact and maintenance-free drive unit for greenhouse automation. Its precise switching system and robust construction ensure long-term reliability in demanding environments.
Aluminum tube for rollup curtains 50 mm Type I
Das ideale Rollschirmrohr für Single-Rollschirme. Es ist ausgestattet mit einer Nut zum Einführen des Gewebes.Material: Aluminium
Motor gearbox RW 245 400-460Volt/3-Phase/3 rpm
Application: Maintenance-free drive for ventilation, shading, and lifting systems in greenhouses and livestock buildings Voltage: 400–450 V, 3-phase Speed: 5 rpm Protection class: IP55 – dust and water resistant End switch: Patented linear limit switch system with high switching accuracy Temperature range: 0–60 °C Features: Quiet operation, self-locking worm gear, optional RPU PositioningUnit or potentiometer kit Ridder Article No.: 502320 The RW245-37 motor gearbox is a rugged, low-maintenance drive unit designed for greenhouse automation. Its precise limit switch system and quiet, self-locking transmission ensure reliable performance in demanding environments.
Motor gearbox Ridder RW403\400-450 Volt - 400-450 V - 3 Phase / 3 rpm - Ridder Art.-Nr.: 502210
Application: Drive unit for ventilation, shading, and lifting systems in greenhouses or livestock buildings Voltage: 400–450 V, 3-phase Speed: 3 rpm Protection class: IP55 – sealed housing with linear limit switch system End switch: Built-in linear system with operating and safety switches (max. 86 turns) Features: Self-locking worm gear, quiet operation, graphite-grey powder coating Optional: RPU PositioningUnit or potentiometer feedback kit Ridder Article No.: 502210 The RW403 motor gearbox is a reliable and quiet drive solution for greenhouse systems. Its integrated switching system ensures precise control and long service life.
Telescopic Shaft 1240-1960mm
Application: For automatic or manual drive systems to open and close side ventilation Length: Adjustable from 1240 mm to 1960 mm Material: Aluminium housing with stainless steel piston rod Mounting: Quick installation via proven double-flat coupling Compatibility: Suitable for fixed-mounted motors Max. drive angle: 34° The Telescopic Shaft 1240–1960 mm is a robust and maintenance-free TransAxleUnit for lightweight greenhouse structures such as poly tunnels. Its telescopic design allows flexible adjustment and easy integration into side ventilation systems.
Mounting plate 105-130\B163 / 413922
Application: Straight mounting plate for RW240/400/600/200 gear motors, RPG150/300/450 PolyGearbox units, RPD150/300/450 PolyDrive motor gearboxes, and RAL240 gear motors Material: Galvanized or bare steel for high stability and corrosion resistance Mounting: Can be attached using bolts or welding Total length: 175.5 mm Length B1 (edge to center of hole): 163 mm Special feature: Custom lengths or configurations available on request Ridder Article No.: 413922 The Mounting Plate 105-130 B163 is a straight steel mounting plate specifically designed for RW240/400/600/200 gear motors, RPG PolyGearbox units, RPD PolyDrive motor gearboxes, and RAL240 gear motors. It ensures secure and stable installation and can be either bolted or welded into place. Thanks to its galvanized or untreated steel construction, the plate offers excellent resistance to corrosion and mechanical stress. Custom lengths or special versions are available on request to ensure optimal compatibility with various systems.
Motor gearbox Ridder RW 45-5\400-450 Volt
Application: Drive unit for ventilation and screen systems in greenhouses or barns Voltage: 400–450 V, 3~, 50 Hz Speed: 5 rpm Limit switch: Integrated linear limit switch system with a 97-turn operating range Features: Self-locking worm gear for secure shaft position at standstill Quiet operation due to optimized gear combinations Maintenance-free and compact design Optional RPU PositioningUnit or potentiometer feedback Graphite-grey powder coating Ridder Article No.: 502020 The RW45-5 / 400–450 V is a powerful and compact gear motor for greenhouse ventilation and shading systems. It features a self-locking worm gear, precise limit switch control, and optional feedback integration for climate automation. Built for durability and quiet operation.
Motor gearbox RW 243 400-460Volt/3-Phase/3 rpm
Application: Compact drive for ventilation, shading, and lifting systems in greenhouses and livestock buildings Voltage: 400–450 V, 3-phase Speed: 3 rpm Protection class: IP55 – dust and water resistant End switch: Integrated linear limit switch system with high switching precision Temperature range: 0–60 °C Features: Self-locking worm gear, quiet operation, optional RPU PositioningUnit or potentiometer kit Ridder Article No.: 502310 The RW243 motor gearbox is a compact and powerful solution for greenhouse automation. Its robust design and precise switching system make it ideal for long-term use in harsh environments.
Motor Gearbox RW245-37/400-450 Fett (Teleskop) Eco / 532259
Application: Maintenance-free gear motor for ventilation, screen, and lifting systems in greenhouses and livestock buildings Material: Robust construction with high protection class IP55 Voltage: 400–450 V, 3-phase Speed: 5 revolutions per minute Limit Switch: Patented linear limit switch system with high switching accuracy Temperature Range: Suitable for ambient temperatures from 0–60 °C Feature: Low-noise operation through optimized gear and worm drive; output shaft compatible with Tower Roller Plus and telescopic systems Ridder Item No.: 532259 The Ridder RW245-37/400-450 Grease Drive is a maintenance-free gear motor designed for ventilation, screen, and lifting systems in greenhouses and livestock facilities. Its robust IP55-rated housing ensures reliable protection against dust and water, even in demanding environments. Operating at 400–450 V and a constant speed of 5 revolutions per minute, the RW245-37 enables precise and dependable motion control. The patented linear limit switch system ensures accurate shaft positioning and high switching precision. The optimized gear and worm drive combination allows for quiet operation and secure self-locking when stationary. The output shaft is specifically designed for direct compatibility with Tower Roller Plus and telescopic systems, eliminating the need for mechanical adaptations. Optionally, the drive position can be transmitted to a climate computer via the RPU PositioningUnit or a potentiometer kit.
Strap tensioner set consisting of tensioner and strap holder
Product type: Strap tensioner set consisting of tensioner and strap holder Material: Both components made of galvanized steel Mounting: Tensioner with 3 pre-drilled holes, holder with 2 pre-drilled holes Function: Self-locking tensioner for secure and durable tensioning Compatibility: Suitable for straps and 8 mm polyester cord Application: Used to tension straps or cords in front of roll screen systems as wind protection The strap tensioner set includes a self-locking tensioner and a matching strap holder – both made of durable galvanized steel. The tensioner features three pre-drilled holes for secure mounting, while the holder has two. This set is ideal for tensioning straps or 8 mm polyester cords, for example in front of roll screen systems to serve as wind protection. The self-locking mechanism ensures reliable tension without the need for readjustment. Thanks to its robust construction and versatile use, the set is a dependable solution for professional greenhouse installations.
1" manual drive adapter
Application: Side ventilation systems in greenhouses Function: Connecting element between a manual drive or worm gear drive and a 1" drive shaft Features: Suitable for manually operated ventilation systems without electric drives Ensures reliable torque transmission between the drive unit and drive shaft Robust construction for long-term use in greenhouse applications Easy integration into new and existing ventilation systems The 1" manual drive adapter is designed as a connecting element between a manual drive or worm gear drive and a 1" drive shaft. It is commonly used in greenhouse side ventilation systems and ensures reliable transmission of operating forces to the ventilation mechanism. Its robust construction makes it suitable for long-term use under demanding greenhouse conditions. The adapter can be installed quickly and easily, making it an ideal solution for both new installations and retrofit applications.
Phormitex PHL 20 Schatt.-Gewebe
Transparent woven fabric, providing a high light transmittance and at the same time saving energy can be used as side ventilation, dividing walls. Due to on sided lamination it is suitable for inside roll-up systems.Note:Further processing such as cutting and sewing is not included the price.
PHL white darkening fabric for for roll-up
Woven fabric with two-sided white lamination, opaque to provide darkening for plants. It can be used as dividing walls or roll-up screens inside and outside.Note:Further processing such as cutting and sewing is not included the price.
Adaptor extended - Tube 27 x 1,5 galvanized
Application: Connector for telescopic systems in greenhouse installations Material: Galvanized steel for high durability and corrosion resistance Compatibility: Suitable for 27 mm pipes with 1.5 mm wall thickness Special feature: Extended version allows integration of a spacer roller The Extended Adapter Pipe 27 × 1.5 Galvanized functions as a connecting element between universal joints and steel pipes in telescopic systems. Its extended design enables the use of a spacer roller, such as those found in TGU TransAxle Units. The high-quality galvanization ensures excellent longevity and corrosion protection.
